Safety Devices 8 point multi-point bolt-in full external/internal roll cage. Mounts to the chassis at 6 external points. Internal B hoop mounts at 2 points.
Front legs mount through front wings down to chassis outrigger. B hoop mounts to the vehicle floor above chassis outrigger.
C hoop ties in to rear door shut assembly. D hoop ties to rear chassis cross member.
Please note that models between 1983 - 1988 had three raised ribs on the roof approx 22mm (7/8') tall. This kind of roof does not work with our external roll cages as the hoops will clash with them. Nor will it fit if the rear seat box is stepped in the rear corner.
- Finished roll cage provided with black powdercoat paint finish unless specified otherwise. Other colours available: grey, blue, silver, white and red. There is a surcharge for colours other than black.
- Roll cage can be provided unpainted by special request (no reduction in price).
- Total weight of roll cage including fitting kit: 124.5kgs.
- Installation time: approx 20 hours. (2 people, 1 day).
Additional Images:
YouTube Video:
Fits These Vehicles:
| Model: | Notes: |
|---|
| Defender 110 | Station Wagon 4-door |
Select the Check box to add accessories to Safari Cage Full Defender 110 NAS
